Hardware Characteristics

 Descriptions

 Model

 KB805

 Chipset

 ASR1803S

 Power Supply Voltage

 DC 12V/1A or Type-C 5V 1A

 Power Consumption

 Normal Operation Power <2W;

 Frequency Band

 FDD LTE: B1/B3/B5/B7/B8/B20/B28

 TDD LTE: B38/B40/B41

 WCDMA: B1/B5/B8

 Rate

 LTE-FDD： Max 150Mbps(DL) Max 50Mbps(UL)

 LTE-TDD： Max   130Mbps(DL) Max 35Mbps(UL)

WCDMA: Max 7.2Mbps(DL) Max   5.76Mbps(UL)

 WIFI Standard

 802.11ax b/g/n , 2.4G (WiFi6)

 LED Indicators

 Power LEDx1

 4G Link LEDx1

 LAN LEDx1

 Network Interface

 1 RJ45 LAN, 10/100Mbps, auto MDI/MDIX

 Antenna

 2*4G*5DBi, 1*2.4G WiFi*5DBi, 1*Decoration

 USIM/SIM

 Nano SIM card

 ESIM

 Optional

 Reset Key

 Long press 5s to restore the factory default setting

 Working Temperature

 Normal: -10°C－+60°C

 Extreme: -30°C－+80°C

 Working Humidity

 10%－95%RH

 Storage Temperature

 -40°C－+85°C
